Car Washing Hose
Type 3A :- is used for delivery of water for sprayers and sprinklers for irrigation system and other industries.
Type 3B :- Car Washing Hose is used for delivery of water at high pressure for car washing in garages & service stations.
Application :
For washing of motor vehicles at service stations.
Construction :
» Special synthetic rubber tube.
» Textile reinforcement .
» Abrastion and weather resistant cover.
Technical Specifications
CONSTRUCTION LINING :
Uniform seamless lining made from a blend of natural and synthetic rubber compound.
REINFORCEMENT:
Plies of woven textile or Braiding of high strength synthetic fiber.
COVER :
Black Cloth Marked finish of weather and abrasion resistant rubber cover for lasting performance while use under severe working conditions. In addition, for 3-B, the cover is highly resistant to oil & weather.
TEMPERATURE RANGE:
- 40° F to + 158°F
LENGTH :
Moulded braided hoses in continuous lengths and Mandrel Made hose 20 Mtr.
COLOR :
Black or as per buyer requirement.
| Hose Size |
Working Pressure |
Bursting Pressure |
Length of each Role |
| inch |
mm |
in PSI |
in BAR |
in PSI |
in BAR |
| 3/8" |
10.0 |
375 |
25 |
1100 |
80 |
50/100 Meters |
| 1/2" |
12.5 |
375 |
25 |
1100 |
80 |
50/100 Meters |
| 5/8" |
16.0 |
375 |
25 |
1100 |
80 |
50/100 Meters |
| 3/4" |
19.0 |
375 |
25 |
1100 |
80 |
50/100 Meters |
