LPG Rubber Hose
Application :
Low pressure LPG Hose for use in house hold application & domestic purpose.
Technical Specifications
CONSTRUCTION LINING :
Seamless tube of blend of natural and synthetic rubber compound resistant to fuel gas, oxygen and other non-combustible gases.
REINFORCEMENT:
High strength Synthetic yarn/fiber braiding.
COVER :
Plain or fluted cover of rubber for lasting performance under sever working conditions.
TEMPERATURE RANGE:
-40° F to + 158°F
LENGTH :
Moulded braided hoses in continuous lengths.
COLOR :
1) Red for fuel gases and 2) Blue or Green for Oxygen and other non-combustible gases.
SAFETY FACTOR :
1 :3 (W.P 200/300 PSI : B.P 600/900 PSI) or 1:4 (W.P 200 PSI : B.P 800 PSI)
| Hose Size |
Working Pressure |
Bursting Pressure |
Length of each Role |
| I.D |
O.D |
in PSI |
in BAR |
in PSI |
in BAR |
| inch |
mm |
mn |
| 1/4" |
6.0 |
12.0 |
300 |
20 |
900 |
60 |
50/100 Meters |
| 5/16" |
8.0 |
14.0 |
300 |
20 |
900 |
60 |
50/100 Meters |
| 3/8" |
9.0 |
16.0 |
300 |
20 |
900 |
60 |
50/100 Meters |
| 1/2" |
12.5 |
19.0 |
300 |
20 |
900 |
60 |
50/100 Meters |
